CE-Certified Cables: Power, Data, Fire-Safe Solutions for Industry & Energy

CE-Certified Power & Data Cables | Industrial, Renewable Energy, Marine Applications

1. Building & Construction Wiring

• Halogen-Free Power Cables (EN 50575):

  • H07Z-K (450/750V):

    • Sizes: 1.5mm² to 240mm².

    • Features: LSZH (Low Smoke Zero Halogen), flame-retardant (IEC 60332-1).

    • Applications: Public buildings, hospitals, tunnels.

  • NYY-J (EN 50525-2):

    • Sizes: 5×6mm², 4×10mm².

    • Voltage: 0.6/1kV.

    • Design: PVC-insulated, armored for direct burial.

    • Applications: Underground power distribution, industrial facilities.

• Flexible Indoor Wiring (EN 50525):

  • H05V-K (300/500V):

    • Sizes: 0.75mm² to 2.5mm².

    • Applications: Lighting circuits, household appliances.

• Fire-Resistant Cables (EN 50200):

  • BS 6387 CWZ (300/500V):

    • Fire Rating: 950°C for 3 hours.

    • Applications: Emergency lighting, fire alarm circuits.

Fire-Resistant Alarm Cable

• • EI 30/60/90 (EN 13501-6):

    • Design: Mineral-insulated (MICC) or ceramic fiber.

    • Certifications: 30/60/90-minute circuit integrity.

---

2. Industrial Automation & Control

• Drag Chain Cables (EN 50382):

  • PUR-Jacketed Cables (600V):

    • Sizes: 24 AWG to 4/0 AWG.

    • Features: 10M+ bend cycles, oil/abrasion-resistant.

    • Applications: CNC machines, robotic arms.

  • CY Shielded Control Cables (EN 50288-7):

    • Sizes: 0.5mm² to 2.5mm² (up to 24 cores).

    • Design: Shielded (tinned copper braid), PVC outer sheath.

    • Applications: PLC systems, sensor networks.

• Fieldbus & Data Cables:

  • PROFINET (EN 50173/IEC 61158):

    • Sizes: 22 AWG, 4-pair.

    • Voltage: 300V.

    • Features: Foiled twisted pairs (F/UTP), IP67-rated connectors.

---

3. EV Infrastructure & Charging

EV Charging Cables (EN 50620):

• • Type 2 Combo (EN 62196-3):

    • Sizes: 3×6mm² + 2×0.75mm².

    • Voltage: 1000V DC / 500V AC.

    • Certifications: IP44/IP67, UV-resistant.

• DC Fast Charging (EN 50620-2):

  • Liquid-Cooled Cables (1500V DC):

    • Sizes: 50mm², 70mm².

    • Design: Shielded for EMI protection, high-current capacity.

---

4. Fire Safety & Survival

• Low-Smoke Halogen-Free (LSHF) Cables (EN 50575):

  • NHXH (0.6/1kV):

    • Features: Flame-retardant (IEC 60332-3), acid gas-free.

  • FR-LSH 2.5mm²:

    • Compliance: EN 60754-1/2 for smoke toxicity.

• Mineral-Insulated Cables (EN 60702):

  • MICC 1C×2.5mm² (750V AC/DC):

    • Fire Rating: 950°C for 3 hours (EN 60331-1).

---

5. Renewable Energy & Grid Integration

Solar PV Cables (EN 50618):
H1Z2Z2-K (1.5kV DC): 4mm² to 16mm² | Photovoltaic arrays, solar farms | UV/ozone-resistant, -40°C to 120°C.

Wind Energy Cables: Torsion-Resistant Cables

---

• 6. Marine & Offshore Applications

Saltwater-Resistant Cables (EN 50525):

H07RN-F (450/750V): IP68-rated, oil-resistant | Shipboard systems, submersible pumps.

• Submarine Power Cables (EN 61892):

  • 220kV XLPE (EN 50502-2):

    • Depth Rating: 2000m.

    • Design: Double-armored, corrosion-resistant.

---

• 7. Data & Communication

• Ethernet Cables (EN 50173):

  • Cat6A (500MHz/10Gbps):

    • Shielded F/UTP, EN 50173-1 compliant.

  • Cat8.2 (2000MHz/40Gbps):

    • EN 61156-8, 30m reach.

• Fiber Optic Cables (EN 60794-2):

  • OS2 Single-Mode (1550nm):

    • Attenuation: ≤0.17 dB/km, EN 60793-2-50 compliant.

---

• 8. Specialty & Harsh Environments

• High-Temperature Cables (EN 50363):

  • MGT 450°C Silicone Cables:

    • Applications: Furnaces, steel plants.

  • TGGT 250°C Fiberglass Cables:

    • Chemical-resistant, extreme heat environments.

• Mining & Tunneling (EN 50214):

  • GGC 4/0 Ground-Check Cables:

    • MSHA-approved, flame-retardant.

• Elevator & Hoist Cables,Cranes, Telescopic machinery, (EN 50214)
