300V Elevator Traveling Cable (Steel Center Core)

Product Overview

The 300V Elevator Traveling Cable with Steel Center Core is a rugged, flexible cable specifically engineered for vertical movement applications in elevators, dumbwaiters, personnel hoists, and material hoists. Featuring a galvanized steel wire rope support core, flame-retardant PVC insulation, and a robust overall jacket, this cable meets stringent UL, CSA, and NEC requirements. Optional shielded pairs and coaxial cables are available for communication and signal transmission.

Applications

• Elevator traveling cables

• Dumbwaiters

• Personnel and material hoists

• Vertical moving equipment requiring mechanical support and electrical connectivity

Standards & Approvals

• Steel support core: Military Specification MIL-W-83420

• Conductor: ASTM B3 (soft annealed copper), ASTM B174 (bunched stranding)

• Insulation & jacketing: UL 62, CSA C22.2 No. 49, NEC, Canadian Electrical Code

• Flame testing: UL 1581, CSA FT-1 (flame rated)

Key Characteristics

Cable Construction

Center Steel Support Cable

• Flexible, performance-rated galvanized steel wire rope support strand manufactured to Military Specification MIL-W-83420.

• Coated with 60°C flame-retardant polyvinyl chloride (PVC) insulation.

• Reinforced with a tightly woven braid of cotton or rayon.

Insulated Conductors

• Soft-annealed, bunched stranded bare copper per ASTM B3 and B174.

• Insulated with flame-retardant 60°C PVC, rated 300V (UL 62, CSA C22.2 No. 49).

• Each conductor is color and number-coded for easy identification.

Shielded Pairs (Optional)

• Two insulated 20 AWG soft-drawn bare copper conductors, PVC insulated, twisted with a bare drain wire.

• Laminated polyester/aluminum foil tape provides 100% shield coverage.

• Overall colored PVC jacket, rated 300V.

Coaxial Cable (Optional)

• RG‑6, 75 ohm, 300V rated coaxial cable.

Fillers

• Fibrous-plied jute fillers create a circular cross-section, enhance torsion stability, and cushion the construction during flexing.

Braid

• A tightly woven braid of cotton, rayon, or equivalent applied over the core to maintain core shape, torsion balance, and add mechanical strength.

Outer Jacket

• Overall PVC jacket – smooth, flexible, abrasion-resistant.

• Complies with flame test requirements of UL 1581 and CSA FT-1.

Technical Parameters

Table 1 – Standard Constructions

Table 2 – Constructions with Shielded Pairs / Coaxial

Table 3 – Complex Multi‑Function Constructions

Note: All values are nominal and subject to standard tolerances. Custom constructions available upon request.

Specifications at a Glance

• Voltage rating: 300V

• Conductor temperature: 60 °C

• Flame retardant: Yes (UL 1581, CSA FT-1)

• Steel core: Galvanized steel wire rope per MIL-W-83420

• Jacket: Smooth, flexible, abrasion-resistant PVC

• Identification: Color and number-coded conductors

• Options: Shielded pairs, RG‑6 coaxial cable
