CSA-Certified Cables & Wires

CSA-Certified Cables & Wires

1. Industrial Power & Control Systems

  • Armored Power Cables (CSA C22.2 No.131)

    • TECK90:

      • Standard TECK90:

        • Sizes: 3C #2 AWG, 4C #1/0 AWG, 5C #4 AWG

        • Voltage: 600V-1000V

        • Design: Stainless steel armor, EPR/PVC insulation.

        • Applications: Oil refineries, chemical plants, industrial tray systems.

      • TECK90-HL (Healthcare/Isolated Ground):

        • Applications: Hospitals, laboratories, cleanrooms.

      • TECK90-HT (High-Temperature):

        • Voltage: 5kV

        • Features: Silicone rubber insulation (150°C rating).

        • Applications: Steel mills, foundries.

    • ACWU90:

      • Sizes: 14 AWG to 1000 kcmil

      • Voltage: 600V

      • Features: Aluminum interlocked armor, waterproof PVC jacket.

      • Applications: Underground duct systems, direct burial.

    • HVTECK (High Voltage):

      • Voltage: 15kV-35kV

      • Design: TR-XLPE insulation, concentric neutral.

      • Applications: Substations, high-voltage industrial grids.

  • Mining & Heavy-Duty Cables

    • GGC (CSA C22.2 No.0.3):

      • Sizes: 2/0, 4/0

      • Voltage: 5kV-15kV

      • Features: MSHA-approved, flame-retardant EPR insulation.

      • Applications: Underground mining conveyor systems.

    • SHD-GC (Shielded Mining Cables):

      • Voltage: 2kV-15kV

      • Design: Reinforced neoprene jacket, CPE insulation.

      • Applications: Tunneling machinery, mining power distribution.

    • MP-GC (Flameproof Trailing Cables):

      • Voltage: 5kV

      • Features: IEC 61892 compliant, GOST-certified.

      • Applications: Continuous mining machines.

2. Building & Infrastructure Wiring

  • Non-Metallic Sheathed Cables (CSA C22.2 No.0.3)

    • NMD90:

      • Sizes: 14/2, 12/2, 10/2

      • Voltage: 600V

      • Features: PVC sheathing, flame-retardant (FT1), sunlight-resistant.

      • Applications: Residential/commercial indoor wiring.

    • NMD90-LT (Low-Temperature):

      • Features: -40°C flexibility for cold environments.

    • NMWU (Underground Feeder):

      • Voltage: 600V

      • Design: Moisture-resistant, direct burial-rated.

      • Applications: Outdoor lighting, garage wiring.

  • Armored Building Cables

    • AC90 (CSA C22.2 No.131):

      • Sizes: 14 AWG to 4/0 AWG

      • Voltage: 600V

      • Features: Interlocked aluminum armor, no conduit required.

      • Applications: Exposed wiring in dry/damp locations.

    • RW90/RWU90 (CSA C22.2 No.0.3):

      • RW90: Thermoplastic insulation, 90°C wet/dry (600V).

      • RWU90: Direct burial, UV-resistant (underground feeders).

3. Renewable Energy Systems

  • Solar Photovoltaic Cables (CSA C22.2 No.271)

    • PV-WIRE:

      • Sizes: 10AWG, 8AWG (Copper/Aluminum)

      • Voltage: 1000V DC

      • Features: UV/ozone-resistant XLPE.

      • Applications: Solar farms, rooftop arrays.

    • USE-2/RHW-2:

      • Voltage: 2000V DC

      • Design: Direct burial-approved, sunlight-resistant.

    • Floating Solar Cables:

      • Voltage: 1.8kV DC

      • Features: Buoyant design, saltwater-resistant.

      • Applications: Marine PV systems.

  • Wind Energy Cables (CSA C22.2 No.0.3)

    • RHH/RHW-2 500kcmil:

      • Voltage: 600V

      • Temperature: 90°C

      • Applications: Onshore/offshore wind turbine wiring.

    • Dynamic Offshore Cables:

      • Voltage: 35kV-66kV

      • Design: Ice-resistant, IEC 62930 compliant.

      • Applications: Offshore wind farms.

  • Energy Storage Systems (ESS)

    • ESS-90 (CSA C22.2 No.107.1):

      • Sizes: 4/0 AWG to 500 kcmil

      • Voltage: 600V

      • Applications: Battery storage, grid-tied inverters.

    • BESS Cables (CSA C22.2 No.0.3):

      • Voltage: 1000V DC

      • Design: Fire-retardant LSZH jacket.

      • Applications: Large-scale battery storage.

4. Flexible Cords & Portable Power

  • Portable Cords (CSA C22.2 No.49)

    • SJOOW:

      • Sizes: 10/3, 12/3, 14/3

      • Voltage: 300V

      • Features: Oil-resistant rubber jacket.

      • Applications: Workshops, temporary power.

    • SEOOW:

      • Voltage: 600V

      • Features: -40°C flexibility, abrasion-resistant.

      • Applications: Shipyards, oil rigs.

    • Type W (CSA C22.2 No.0.3):

      • Sizes: 8/3, 6/3

      • Voltage: 600V

      • Design: Submersible (IP68), reinforced neoprene.

      • Applications: Pumps, marine equipment.

  • Diesel Locomotive Cables (CSA C22.2 No.127)

    • DLO 2/0, 4/0:

      • Voltage: 2000V

      • Design: Oil-resistant EPR insulation.

      • Applications: Oil rigs, heavy machinery.

5. Communication & Data Transmission

  • Ethernet Cables (CSA C22.2 No.214)

    • CMG (General Use):

      • Cat5e (100MHz), Cat6 (250MHz).

    • CMR (Riser-Rated):

      • Low-smoke halogen-free (LSZH), Cat6A (500MHz/10Gbps).

    • CMP (Plenum-Rated):

      • Cat8.2 (2000MHz/40Gbps), TIA-568.2-D compliant.

  • Fiber Optic Cables (CSA C22.2 No.0.3)

    • Indoor/Outdoor Fiber:

      • OM3/OM4 (multimode), OS2 G.654 (single-mode).

      • Applications: Data centers, telecom networks.

    • Armored Fiber:

      • Titanium-armored, DNV-OS-E402 compliant (subsea applications).

  • Coaxial & Broadcast Cables (CSA C22.2 No.0.3)

    • RG6/RG11: Low-loss, IEC 61196 compliant.

    • LMR-400: Shielded, flexible (wireless infrastructure).

6. Marine & Offshore Applications

  • Shipboard Cables (CSA C22.2 No.0.6)

    • STOOW:

      • Voltage: 600V

      • Features: Neoprene jacket, saltwater-resistant.

    • Marine Battery Cables:

      • Sizes: 500 MCM

      • Design: Tin-plated copper, corrosion-resistant.

  • Dynamic Umbilicals (CSA C22.2 No.0.3)

    • 3C×300mm²:

      • Applications: ROV operations, subsea power distribution.

    • Subsea Power Cables:

      • Voltage: 6.6kV

      • Design: Titanium-armored, DNV-OS-E402 compliant.

      • Applications: Deep-sea mining.

7. High-Temperature & Fire Survival Cables

  • Mineral Insulated (MI) Cables (CSA C22.2 No.139)

    • MICC 1C×2.5mm²:

      • Temperature: 950°C for 3 hours.

      • Applications: Nuclear plants, emergency circuits.

    • Ceramic Fiber Cables:

      • Temperature: 1800°C (short-term).

      • Applications: Aerospace, blast furnaces.

  • High-Temp Industrial Cables

    • TGGT (CSA C22.2 No.0.3):

      • Sizes: 20-8 AWG

      • Voltage: 600V

      • Features: Silicone insulation, 250°C rating.

      • Applications: Foundries, kilns.

    • MGT (CSA C22.2 No.0.3):

      • Voltage: 600V

      • Temperature: 450°C (fiberglass braided).

      • Applications: High-heat industrial zones.

8. Tray, Utility & Custom Solutions

  • Tray Cables (CSA C22.2 No.0.3)

    • TC/TC-ER:

      • TC: 4C-6C, unshielded (600V, PVC/XLP insulation).

      • TC-ER: Shielded, for exposed industrial automation.

    • PLTC (Power-Limited):

      • Voltage: 300V

      • Applications: Control systems, instrumentation.

  • Underground Distribution (UD) Cables

    • AL 600V-UD Duplex/Triplex:

      • Applications: Service drops, rural electrification.

    • HISCORE UD Cables:

      • Design: High-strength aluminum, UV-resistant.

      • Applications: Harsh outdoor environments.

  • Custom Composite Cables

    • Hybrid Cables:

      • RG6+CAT5e+光纤 (home automation, smart grids).

    • Eco-Friendly Solutions:

      • Recyclable XLPE, seaweed-based jackets (RoHS/REACH compliant).
