SOOW Portable Power Cable | 90°C Oil-Resistant | UL 62 & CSA Certified

Product Overview

SOOW Portable Power Cable is a heavy-duty flexible cord designed for demanding industrial and commercial applications requiring exceptional durability, oil resistance, and flexibility. Featuring EPDM insulation, CPE jacket, and ASTM-compliant stranded copper conductors, this cable meets UL 62, CSA C22.2 No. 49, OSHA, and MSHA standards. Rated for 600V and 90°C operation, it is ideal for powering portable tools, machinery, and equipment in rugged environments.

Key Features

  • Oil & Abrasion Resistance: CPE outer jacket protects against oils, chemicals, and mechanical wear.

  • Flexible Design: Stranded copper conductors ensure superior bendability for portable applications.

  • High-Temperature Rating: Suitable for continuous use at 90°C in dry or damp locations.

  • Safety Compliance: UL, CSA, OSHA, and MSHA approved for industrial safety.

  • Color-Coded Insulation: EPDM insulation with color coding for easy phase identification.

Construction Details

Component Specification
Conductors Stranded bare copper (ASTM B3/B174 compliant).
Insulation Color-coded EPDM (ethylene propylene diene monomer).
Jacket Black chlorinated polyethylene (CPE), oil/moisture/abrasion resistant.
Voltage Rating 600V AC.
Temperature Range -40°C to +90°C (operating).
Flexibility High strand count for repeated bending and movement.

Technical Specifications

  • Standards Compliance: UL 62, CSA C22.2 No. 49, OSHA 29 CFR 1910, MSHA Part 18.

  • Conductor Sizes: Ranges from 18 AWG to 500 kcmil (see technical tables for details).

  • Insulation Thickness: Meets UL/CSA requirements for voltage and temperature ratings.

  • Flame Resistance: Flame-retardant per UL 62 vertical flame test.

  • Environmental Resistance: Oil, sunlight, moisture, and abrasion resistant.

Applications

SOOW Cable is engineered for:

  • Industrial Machinery: Portable tools, pumps, welders, and compressors.

  • Construction Sites: Temporary power distribution for equipment and lighting.

  • Agriculture: Farm machinery, irrigation systems, and outdoor installations.

  • Entertainment: Stage lighting, audio systems, and mobile generators.

  • Mining Operations: MSHA-approved for use in mining equipment.

  • Marine & Offshore: Damp environments with oil exposure.

Installation Guidelines

  • Bending Radius: Minimum 5x cable diameter to maintain jacket integrity.

  • Temperature Limits: Avoid installation below -40°C without pre-conditioning.

  • Pull Tension: Use proper grips to prevent conductor damage during pulling.

  • Termination: Use strain relief connectors for repeated flexing applications.

  • Prohibited Uses: Not for direct burial or permanent fixed installations.

Why Choose SOOW Portable Power Cable?

  • Durability: Withstands harsh industrial environments, including oil and chemical exposure.

  • Certified Safety: Meets stringent UL, CSA, OSHA, and MSHA requirements.

  • Cost Efficiency: Reduced downtime due to robust construction and long service life.

  • Versatility: Suitable for indoor/outdoor use in dry or damp locations.
