Product Overview
The CKJ86/NC marine control cable combines XLPE insulation with a low smoke zero halogen (LSZH) sheath and tinned copper braid armor. Designed for maximum safety and reliability, it provides excellent fire resistance and EMI protection for demanding marine and industrial environments.
Key Features
-
Fire Resistant: Maintains circuit integrity during fire (IEC 60331)
-
Flame Retardant: Superior flame spread resistance (IEC 60332-1 & 60332-3-22)
-
Low Smoke Zero Halogen: Minimal smoke and toxic gas emission
-
Copper Braid Armor: Provides mechanical protection and EMI shielding
-
XLPE Insulation: High thermal stability (90°C operating temperature)
-
Flexible Design: Copper braid armor allows better flexibility than steel armor
Applications
-
Offshore platforms and oil rigs
-
Shipboard power and control systems
-
Marine instrumentation and lighting
-
Chemical plants and hazardous areas
-
Power stations and mining operations
-
Industrial automation systems
Technical Specifications
| Parameter | Details |
|---|---|
| Rated Voltage | 150/250V |
| Operating Temperature | 90°C |
| Conductor | Tinned or plain stranded annealed copper |
| Insulation | Mica glass tape + XLPE |
| Armor | Tinned/plain copper wire braid |
| Outer Sheath | Halogen-free flame retardant thermoplastic (SHF1) |
| Core Range | 1-37 cores |
| Cross Sections | 0.5mm², 0.75mm², 1.0mm², 1.5mm², 2.5mm² |
Compliance Standards
-
IEC 60092-350, 376 - Marine cable design
-
IEC 60228 - Conductors
-
IEC 60092-360 - Insulation and sheath
-
IEC 60331 - Fire resistance
-
IEC 60332-1 & 60332-3-22 - Flame retardancy
-
IEC 60754 - Halogen-free
-
IEC 61034 - Low smoke density
Construction Details
-
Series Code: CK (Marine & Offshore Control Cable)
-
Conductor: Tinned/plain stranded annealed copper wire
-
Insulation: Mica glass tape + XLPE insulation
-
Armor: Tinned/plain copper wire braid (Code 8)
-
Outer Sheath: Halogen-free flame retardant thermoplastic (SHF1)
-
Sheath Color: Black (other colors available)
-
Flammability Code: NC (Halogen Free, Low Smoke, Fire Resistant)
Product Advantages
-
Enhanced Safety: Fire-resistant construction maintains circuit integrity in emergencies
-
EMI Protection: Copper braid armor provides excellent electromagnetic shielding
-
Corrosion Resistance: Tinned copper components ensure longevity in marine environments
-
Environmental Safety: Zero halogen and low smoke emission protect personnel and equipment
-
Flexibility: Copper braid armor offers better bending capability than steel armor
-
International Compliance: Meets all relevant IEC standards for global acceptance
