H05RNH2-F 2 Cores Flat Cable
Product Overview
The H05RNH2-F is a 2 cores flat cable designed with a polychloroprene or equivalent synthetic rubber sheath for lighting festoons. It features flexible bare or tinned copper Class 5 conductors, special crosslinked elastomer insulation, and a special crosslinked elastomer outer sheath for high temperatures.
The cable is available in black or green as standard, with other colours available on request. Core colours are Brown + Blue for the 2-core configuration.
Key Features & Benefits
-
Flat Construction: 2 cores flat cable design ideal for lighting festoon applications.
-
Flexible Conductors: Flexible bare or tinned copper Class 5 for ease of installation.
-
High-Temperature Elastomer: Special crosslinked elastomer insulation and outer sheath for high temperatures.
-
Flame Retardant: Complies with IEC 60332-1.
-
Weather Resistant: Good weather resistance for outdoor applications.
-
Chemical Resistance: Good chemical resistance.
-
Water Proof: Accidental water proof.
-
Voltage Rating: 300/500V.
-
Operating Temperature: -25°C to +50°C.
-
Short-Circuit Temperature: 200°C max. conductor temperature.
Typical Applications
-
Lighting festoons
-
Indoor and outdoor decorative lighting
-
Temporary and permanent lighting installations requiring flat cable
Construction Details
-
Conductor: Flexible bare or tinned copper Class 5
-
Insulation: Special crosslinked elastomer
-
Outer Sheath: Special crosslinked elastomer for high temperatures
-
Sheath Colour: Black or Green (other colours on request)
-
Core Colours: 2 cores = Brown + Blue
Technical Specifications
Electrical Characteristics
| Parameter | Value |
|---|---|
| Rated Voltage Uo/U (Um) | 300 / 500 V |
| Maximum Permissible Nominal Current | 16 A (1.5 mm²) / 16.2 A (2.5 mm²) |
| Voltage Drop, Single Phase | 27.0 V/A.km (1.5 mm²) / 25 V/A.km (2.5 mm²) |
Mechanical & Thermal Characteristics
| Parameter | Value |
|---|---|
| Cable Flexibility | Flexible |
| Operating Temperature Range | -25°C to +50°C |
| Short-Circuit Max. Conductor Temperature | 200°C |
| Water Proof | Accidental |
| Weather Resistance | Good |
| Chemical Resistance | Good |
Fire Performance
| Parameter | Value |
|---|---|
| Flame Retardant | IEC 60332-1 |
Parameter Table – H05RNH2-F 2 Cores Flat Cable
| Characteristic | Value | Value |
|---|---|---|
| Conductor Material | Bare Copper | Bare Copper |
| Conductor Flexibility | Flexible Class 5 | Flexible Class 5 |
| Outer Sheath | Elastomer | Elastomer |
| Number of Cores | 2 | 2 |
| Conductor Cross-Section | 1.5 mm² | 2.5 mm² |
| Approximate Weight | 132 kg/km | 138 kg/km |
| External Dimensions | 5.3 mm x 13.3 mm | 5.3 mm x 13.3 mm |
Note: All values are nominal as provided in the source specification. Actual dimensions and weights may vary within standard manufacturing tolerances.
Standards & Compliance
-
Flame Retardant: IEC 60332-1
Ordering Information
To request a quote or place an order, please provide the following information:
-
Product Type: H05RNH2-F 2 Cores Flat Cable
-
Voltage Rating: 300/500V
-
Conductor Cross-Section: 1.5 mm² or 2.5 mm²
-
Conductor: Flexible bare or tinned copper Class 5
-
Insulation: Special crosslinked elastomer
-
Outer Sheath: Special crosslinked elastomer, Black or Green (other colours on request)
-
Quantity: Total length in meters
